DW-BJRR2PxxT
DW-BJRR2PxxTLX
DW-BJRR2PxxTS

Blackjack Rack 2U 12-bay server, 32GB RAM, dual processor
NDAA TAA


Features
  • 5 year warranty, next business day on-site hardware service*, keep your hard drive  - *after remote diagnosis
  • Supports ONVIF conformant IP cameras
  • Storage options 64-192TB raw internal storage with RAID5
  • Hot-Swappable HDDs
  • Redundant power supply
  • Dedicated GPU for client application for easy configuration
  • Intel® Xeon® processor
  • Dual network ports
  • Windows 10®, Ubuntu® Linux®, Windows Server® 2019 OS on NVMe SSD, RAID1
  • Hosting DW Spectrum® for setup, configuration and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • Two (2) 4-channel licenses included for a total of 8 recording channels (DW-SPECTRUMLSC004)
  • No annual maintenance fees
  • Simple enterprise scalability and auto device discovery
  • Dual-stream recording
  • Rail kit included
  • USB mouse and keyboard included
  • Show More

Max throughput and IP camera support

This Blackjack® server can record and manage single-sensor and multi-sensor IP cameras of any resolution up to of 600Mbps throughput.

Next business day onsite hardware repair after remote diagnosis

If an issue occurs with your product that cannot be resolved by phone, DW will dispatch a certified technician to attempt repair of your machine at your place of business, usually the next business day.

Keep your drive after replacement to ensure data security

Our Keep Your Drive Warranty delivers users replacement hard drives, without the need to return the defective drives. Users can keep their drives and protect their data and their customer’s privacy.

DW Spectrum® IPVMS

DW Spectrum® IPVMS is an endlessly customizable IP Video Management platform that gives users the ability to create tailored network video solutions for any type of project, from the office or on in the field.

Designed and commissioned in the U.S.A

All DW recorders, workstations and NAS devices are designed, assembled and inspected in our California facility. Each product undergoes multiple levels of quality control to guarantee the highest quality and performance.

Dual network cards

Optimize network bandwidth by utilizing dual network ports, to build a separate network for the surveillance system and keep that traffic off the main network, reserved for the NVR’s communication.

Dual power supply

Redundancy for reliability.

Hot-swappable HDDs

When a drive needs to be replaced, you can easily hot-swap it with a new one, while the system is still running. There is no need to power down and lose important minutes of data to maintain your system’s drives healthy and operating.

Specifications

Video
CPU Dual Intel® Xeon® Silver processor
Display Modes Unlimited, Sequence, Customizable
Display Speed Up to 30fps per channel
Local Video Output Resolution HD 1080p
Local Video Outputs True HD, DVI, 1 display output at a time, 4x Mini DisplayPort outputs, Mini Display Port to true HD adapter (included), 3x Mini DisplayPort outputs
Max video storage rate (Mbps) 600Mbps
Memory 32GB
Video Card On-board Intel Graphics
Video Compression H.264, H.265
Video Operating System Linux® OS, Windows®10, Windows Server®
OS on SSD 2x 240GB SSD (RAID1 mirrored)
Storage
Raw internal storage options 64TB  80TB  96TB  112TB  128TB  144TB  160TB  176TB  192TB
Max HDD Bay Max HDD Bay (AU6112)
Maximum Storage 192TB RAID0, 1 5, 6, 10 available
RAID Options RAID5, OS RAID1
Performance
Playback Functions Timeline, Calendar, Event search, Thumbnail search, Smart motion search
PTZ control ONVIF
Recording Modes Continuous, Motion detection, Motion + low res always, Object only, Object + Low res, Motion + Object, Motion + Object + Low res
System Operation Graphical user interface (GUI), USB mouse (included), Remote via DW Spectrum IPVMS
Network
Backup Network backup via DW Spectrum IPVMS
Ethernet Ports 2x 1G Ethernet (RJ45)
Network Remote Software DW Site Viewer for Apple TV, DW Spectrum Mobile App, Cross-platform - Windows®, Linux Ubuntu® and Mac®, DW Mobile Plus
Pre-loaded VMS software DW Spectrum® IPVMS
Electrical
Power Consumption 750W dual power, Redundant power supply, A UPS is recommended
General
Accessories Keyboard, Mouse
Certification NDAA Compliance, ONVIF Conformant, TAA Compliance
Certification (Product Specification) CE, FCC, RohS, KCC
Form Factor Rack mount
Included IP licenses 8
Operating Temperature and Humidity 41 ~ 104 °F (5~40 °C), 20 ~ 90% RH
Rail kit Included
Recorder Dimensions (H X W X D) 19" x 28.25" x 3.41" (482.6 x 717.55 x 86.61mm)
Recording Licenses (Optional. Sold Separately) DW-SPECTRUMLSC001 - Single DW Spectrum® IPVMS Recording License
DW-SPECTRUMLSC004 - Four (4) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC010 - Ten (10) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum® IPVMS Recording Licenses
DW-SPCP04LSC004 - Four (4) DW Spectrum® Analog Encoder IPVMS Licenses
DW-SPIOLSC001 - Single DW Spectrum® I/O Module IPVMS License
DW-SPCP16LSC016 - Sixteen (16) DW Spectrum® Analog Encoder IPVMS Licenses
DW-SPVWALL1X2 - Single DW Spectrum® Video Wall IPVMS License
Custom-ordered licenses are available by request.
Lifetime upgrades are included with no annual renewal fees.
Serial ports ONVIF
USB interface Yes
Warranty Next business day on-site hardware service (after remote diagnosis), keep your hard drive

Part Numbers

Model #*

Usable Storage Size**

Open Drive Bays

DW-BJRR2P64T
46TB (RAID5)
8
DW-BJRR2P80T
64TB (RAID5)
7
DW-BJRR2P96T
80TB (RAID5)
6
DW-BJRR2P112T
96TB (RAID5)
5
DW-BJRR2P128T
112TB (RAID5)
4
DW-BJRR2P144T
128TB (RAID5)
3
DW-BJRR2P160T
144TB (RAID5)
2
DW-BJRR2P176T
160TB (RAID5)
1
DW-BJRR2P192T
176TB (RAID5)
---
* For Linux OS models, add LX at the end of the part number.
* For Windows Server OS models, add S at the end of the part number.

** RAID5 configuration reduces raw storage size by the equivalent of one (1) HDD size.

Purchasing Options

DW Spectrum IPVMS Licensing Options
DW Spectrum IPVMS Licensing Options

Part Number

Description

DW-SPECTRUMLSC001
Single DW Spectrum IPVMS License, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLSC004
Four (4) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLSC010
Ten (10) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLSC020
Twenty (20)  DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLSC050
Fifty (50)  DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLSC100
One Hundred (100)  DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPCP04LSC004
Single DW Spectrum IPVMS License - allows up to 4-channel or recording when used with DW-CP04 and DW-CP16,  No Annual Renewal, No Upgrade Required.
DW-SPVWALL1X2Single DW Spectrum IPVMS Video Wall License - 1 Operator, 2 Monitors,  No Annual Renewal, No Upgrade Required.

Additional Hardware Options (Available at time of initial order only):

Part Number

Description

DW-BJRR32GB
32GB Ram Upgrade for Blackjack RACK.
DW-BJRR4NIC Low Profile Quad Port 1GbE RJ45 for Blackjack RACK.
DW-BJRR10GBN Low Profile Dual Port 10Gb SFP+ NIC for Blackjack RACK.
DW-BJRR4HSERV Dell 4HR same day service for DW-BJRR and DW-BJRR2P servers.

Documents

Title Type
Blackjack Brochure
pdf Download
Blackjack Rack quick setup guide
pdf Download
Blackjack Rack sell sheet
pdf Download
Blackjack Rack support guide
pdf Download
DW-BJRR2 CAD drawing
dwg Download
DW-BJRR2 UL certificate
pdf Download
DW-BJRR2P AE specifications
doc Download
DW-BJRR2P datasheet
pdf Download

Software

Gen 5

Linux OS
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVMS Client v5.0.0.36183 Linux x64 Bit deb v5.0.0.36183 02/09/2023 174.78 MB Download
DW Spectrum IPVMS Server v5.0.0.36183 Linux x64 Bit deb v5.0.0.36183 02/09/2023 84.64 MB Download
DW Witness Plugin for Linux v5.0.0.35746 so v5.0.0.35746 10/21/2022 0.21 MB Download
Windows OS
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVMS Client v5.0.0.36183 Windows x64 Bit exe v5.0.0.36183 01/12/2023 146.68 MB Download
DW Spectrum IPVMS Full Software v5.0.0.36183 Windows x64 Bit exe v5.0.0.36183 01/12/2023 193.32 MB Download
DW Spectrum IPVMS Server v5.0.0.36183 Windows x64 Bit exe v5.0.0.36183 01/12/2023 94.19 MB Download
DW Witness Plugin for Windows v5.0.0.35746 dll v5.0.0.35746 10/21/2022 0.09 MB Download
MAC OS
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVMS Client v5.0.0.36183 Mac ARM x64 Bit zip v5.0.0.36183 01/27/2023 124.84 MB Download
DW Spectrum IPVMS Client v5.0.0.36183 Mac x64 Bit zip v5.0.0.36183 01/27/2023 136.26 MB Download
Plug-in
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVSM Paxton Plug-in v5.0.0.36183-Net2v5 exe v5.0.0.36183 01/12/2023 1.24 MB Download
DW Spectrum IPVSM Paxton Plug-in v5.0.0.36183-Net2v6 exe v5.0.0.36183 01/12/2023 1.28 MB Download
DW Spectrum IPVMS C•CURE 9000 Plug-in v5.0 zip - 5.0 11/16/2022 DW Spectrum 25.77 MB Download
DW Witness Plugin for Linux v5.0.0.35746 so v5.0.0.35746 10/21/2022 0.21 MB Download
DW Witness Plugin for Windows v5.0.0.35746 dll v5.0.0.35746 10/21/2022 0.09 MB Download

Version 4.2

Linux OS
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVMS Client v4.2.0.32842 Linux x64 Bit deb v4.2.0.32842 09/20/2021 167.46 MB Download
DW Spectrum IPVMS Server v4.2.0.32842 Linux x64 Bit deb v4.2.0.32842 09/20/2021 63.82 MB Download
Windows OS
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVMS Full Software v4.2.0.32842 Windows x64 Bit exe v4.2.0.32842 09/20/2021 185.34 MB Download
DW Spectrum IPVMS Server v4.2.0.32842 Windows x64 Bit exe v4.2.0.32842 09/20/2021 94.23 MB Download
DW Spectrum IPVMS Client v4.2.0.32842 Windows x64 Bit exe v4.2.0.32842 09/20/2021 129.20 MB Download
MAC OS
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVMS Client v4.2.0.32842 Mac dmg v4.2.0.32842 09/20/2021 121.98 MB Download
Plug-in
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVSM Paxton Plug-in v4.2.0.32842-Net2v5 exe v4.2.0.32842 09/20/2021 1.24 MB Download
DW Spectrum IPVSM Paxton Plug-in v4.2.0.32842-Net2v6 exe v4.2.0.32842 09/20/2021 1.27 MB Download
