DW-BJRR2XxxT,DW-BJRR2XxxTLX,DW-BJRR2XxxTS

Blackjack Rack 2U 18-bay server with 32GB dual processor, RAID5/6 options
NDAA TAA


Features
  • 5 year warranty, next business day on-site hardware service*, keep your hard drive  - *after remote diagnosis
  • Supports all ONVIF conformant IP cameras
  • Storage options 208-288TB raw internal storage
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 600Mbps throughput
  • Hot Swappable HDDs
  • OS RAID 1, Data RAID5, 6 options
  • Redundant power supply
  • 6x 1GB Base-T Etherner Ports, 2x 10G SFP+ Fiber
  • Windows 10® IoT, Ubuntu® Linux®, Windows Server 2019® OS options on separate SSD
  • Dedicated RAID controller
  • Hosting DW Spectrum® for setup, configuration, monitoring and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • Two (2) 4-channel licenses included for a total of 8 recording channels (DW-SPECTRUMLSC004).
  • No annual maintenance fees
  • Dual stream recording
  • Rail kit included
  • USB mouse and keyboard included
  • Show More

Max throughput and IP camera support

This Blackjack® server can record and manage single-sensor and multi-sensor IP cameras of any resolution up to of 600Mbps throughput.

Next business day onsite hardware repair after remote diagnosis

If an issue occurs with your product that cannot be resolved by phone, DW will dispatch a certified technician to attempt repair of your machine at your place of business, usually the next business day.

Keep your drive after replacement to ensure data security

Our Keep Your Drive Warranty delivers users replacement hard drives, without the need to return the defective drives. Users can keep their drives and protect their data and their customer’s privacy.

DW Spectrum® IPVMS

DW Spectrum® IPVMS is an endlessly customizable IP Video Management platform that gives users the ability to create tailored network video solutions for any type of project, from the office or on in the field.

Designed and commissioned in the U.S.A

All DW recorders, workstations and NAS devices are designed, assembled and inspected in our California facility. Each product undergoes multiple levels of quality control to guarantee the highest quality and performance.

Dual network cards

Optimize network bandwidth by utilizing dual network ports, to build a separate network for the surveillance system and keep that traffic off the main network, reserved for the NVR’s communication.

Dual power supply

Redundancy for reliability.

Hot-swappable HDDs

When a drive needs to be replaced, you can easily hot-swap it with a new one, while the system is still running. There is no need to power down and lose important minutes of data to maintain your system’s drives healthy and operating.

Specifications

Video
CPU Dual Intel® Xeon® Silver processor
Display Modes Unlimited, Sequence, Customizable
Local Video Outputs 1 display output at a time, Mini Display Port to true HD adapter (included), 3x Mini DisplayPort outputs
Memory 32GB
Video Card NVIDIA T400 2GB
Video Compression H.264, H.265
Video Operating System Windows Server®, Windows®10 IoT, Linux Ubuntu® 20.04 LTS
OS on SSD 2x 240GB SSD (RAID1 mirrored)
Storage
Max HDD Bay 18x SAS HDDs, 26x SAS HDDs
Performance
Playback Functions Timeline, Calendar, Event search, Thumbnail search, Smart motion search
PTZ control ONVIF
Recording Modes Continuous, Motion detection, Motion + low res always, Object only, Object + Low res, Motion + Object, Motion + Object + Low res
Network
Backup Network backup via DW Spectrum IPVMS
Ethernet Ports 6x 1GB Ethernet (RJ45), 6x 1GB Base-T Ethernet Ports, 2x 10GB SFP+ Fiber
Network Remote Software DW Site Viewer for Apple TV, DW Spectrum Mobile App, Cross-platform - Windows®, Linux Ubuntu® and Mac®, DW Mobile Plus
Pre-loaded VMS software DW Spectrum® IPVMS
General
Accessories Keyboard, Mouse
Certification NDAA Compliance, ONVIF Conformant, TAA Compliance
Certification (Product Specification) CE, FCC, RohS, KCC
Dimensions 17.6" x 31.9" x 3.41" (447.04 x 810.26 x 86.61mm)
Form Factor Rack mount
Included IP licenses 8
Max video storage rate (Mbps) 600Mbps
Operating Temperature and Humidity 41 ~ 104 °F (5~40 °C), 20 ~ 90% RH
Power Consumption Redundant power supply, A UPS is recommended, 1000W dual power
RAID Options RAID5, RAID6, OS RAID1
Rail kit Included
Serial ports ONVIF
System Operation Graphical user interface (GUI), USB mouse (included), Remote via DW Spectrum IPVMS
USB interface Yes
Warranty 5 Year Warranty, Next business day on-site hardware service (after remote diagnosis), keep your hard drive

Part Numbers

Model #*

Open Drive Bays

Available Storage, RAID5**

Available Storage, RAID6**

DW-BJRR2X208T 16TB drives, 5 open drive bays 192TB 176TB
DW-BJRR2X224T 16TB drives, 4 open drive bays 208TB 192TB
DW-BJRR2X240T 16TB drives, 3 open drive bays 224TB 208TB
DW-BJRR2X256T 16TB drives, 2 open drive bays 240TB 224TB
DW-BJRR2X272T 16TB drives, 1 open drive bay 256TB 240TB
DW-BJRR2X288T 16TB drives, no open drive bays 272TB 256TB
* For Linux OS models, add LX at the end of the part number.
* For Windows Server OS models, add S at the end of the part number.

** RAID5 configuration reduces raw storage size by the equivalent of one (1) HDD size.
** RAID6 configuration reduces raw storage size by the equivalent of two (2) HDDs size.

Purchasing Options

DW Spectrum IPVMS Licensing Options
DW Spectrum IPVMS Licensing Options

Part Number

Description

DW-SPECTRUMLSC001
Single DW Spectrum IPVMS License, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS004
Four (4) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS010
Ten (10) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS020
Twenty (20)  DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS050
Fifty (50)  DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS100
One Hundred (100)  DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPCP04LSC004
Single DW Spectrum IPVMS License - allows up to 4-channel or recording when used with DW-CP04 and DW-CP16,  No Annual Renewal, No Upgrade Required.
DW-SPVWALL1X2Single DW Spectrum IPVMS Video Wall License - 1 Operator, 2 Monitors,  No Annual Renewal, No Upgrade Required.

Additional Hardware Options (Available at time of initial order only):

Part Number

Description

DW-BJRR32GB
32GB Ram Upgrade for Blackjack RACK.
DW-BJRR4NIC Low Profile Quad Port 1GbE RJ45 for Blackjack RACK.
DW-BJRR10GBN Low Profile Dual Port 10Gb SFP+ NIC for Blackjack RACK.
DW-BJRR4HSERV Dell 4HR same day service for DW-BJRR and DW-BJRR2P servers.

Documents

Title Type
Blackjack Brochure
pdf Download
Blackjack Rack quick setup guide
pdf Download
Blackjack Rack support guide
pdf Download
DW-BJRR2 CAD drawing
dwg Download
DW-BJRR2X A&E specifications
doc Download
DW-BJRR2X datasheet
pdf Download
DW-BJRR2X datasheet - French
pdf Download
DW-BJRR2X datasheet - Spanish
pdf Download

Software

Gen 5

Linux OS
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVMS Client v5.0.0.35746 Linux x64 Bit zip v5.0.0.35746 10/21/2022 174.82 MB Download
DW Spectrum IPVMS Server v5.0.0.35746 Linux x64 Bit deb v5.0.0.35746 10/24/2022 84.53 MB Download
DW Witness Plugin for Linux v5.0.0.35746 so v5.0.0.35746 10/21/2022 0.21 MB Download
Windows OS
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVMS Client v5.0.0.35746 Windows x64 Bit exe v5.0.0.35746 10/21/2022 146.63 MB Download
DW Spectrum IPVMS Full Software v5.0.0.35746 Windows x64 Bit exe v5.0.0.35746 10/21/2022 193.15 MB Download
DW Spectrum IPVMS Server v5.0.0.35746 Windows x64 Bit exe v5.0.0.35746 10/21/2022 94.03 MB Download
DW Witness Plugin for Windows v5.0.0.35746 dll v5.0.0.35746 10/21/2022 0.09 MB Download
MAC OS
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVMS Client v5.0.0.35746 Mac ARM x64 Bit zip v5.0.0.35746 10/21/2022 124.81 MB Download
DW Spectrum IPVMS Client v5.0.0.35746 Mac x64 Bit zip v5.0.0.35746 10/21/2022 136.07 MB Download
Plug-in
Title Type Release Notes Version Upload Date Compatibility Size
DW Spectrum IPVMS C•CURE 9000 Plug-in v5.0 zip - 5.0 11/16/2022 DW Spectrum 25.77 MB Download
DW Spectrum IPVSM Paxton Plug-in v5.0.0.35746-Net2v5 exe v5.0.0.35746 10/21/2022 1.24 MB Download
DW Spectrum IPVSM Paxton Plug-in v5.0.0.35746-Net2v6 exe v5.0.0.35746 10/21/2022 1.28 MB Download
DW Witness Plugin for Linux v5.0.0.35746 so v5.0.0.35746 10/21/2022 0.21 MB Download
DW Witness Plugin for Windows v5.0.0.35746 dll v5.0.0.35746 10/21/2022 0.09 MB Download
