Video | |
---|---|
CPU | Dual Intel® Xeon® Silver processor |
Display Modes | Unlimited, Sequence, Customizable |
Local Video Outputs | 1 display output at a time, Mini Display Port to true HD adapter (included), 3x Mini DisplayPort outputs |
Max video storage rate (Mbps) | 600Mbps |
Memory | 32GB |
Video Card | NVIDIA T400 2GB |
Video Compression | H.264, H.265 |
Video Operating System | Linux® OS, Windows Server®, Windows®10 IoT |
OS on SSD | 2x 240GB SSD (RAID1 mirrored) |
Storage | |
Raw internal storage options |
![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() |
Maximum Storage | Max raw 416TB |
RAID Options | RAID5, RAID6, OS RAID1 |
Performance | |
Playback Functions | Timeline, Calendar, Event search, Thumbnail search, Smart motion search |
PTZ control | ONVIF |
Recording Modes | Continuous, Motion detection, Motion + low res always, Object only, Object + Low res, Motion + Object, Motion + Object + Low res |
System Operation | Graphical user interface (GUI), USB mouse (included), Remote via DW Spectrum IPVMS |
Network | |
Backup | Network backup via DW Spectrum IPVMS |
Ethernet Ports | 2x 1G Ethernet (RJ45), 2x 1GB Ethernet (RJ45), 2x 1GB Base-T Ethernet Port, iDRAC9 Enterprise |
Network Remote Software | DW Site Viewer for Apple TV, DW Spectrum Mobile App, Cross-platform - Windows®, Linux Ubuntu® and Mac®, DW Mobile Plus |
Pre-loaded VMS software | DW Spectrum® IPVMS |
Electrical | |
Power Consumption | Redundant power supply, A UPS is recommended, 1000W dual power |
General | |
Accessories | Keyboard, Mouse |
Certification | NDAA Compliance, ONVIF Conformant, TAA Compliance |
Certification (Product Specification) | CE, FCC, RohS, KCC |
Form Factor | Rack mount |
Included IP licenses | 8 |
Operating Temperature and Humidity | 41 ~ 104 °F (5~40 °C), 20 ~ 90% RH |
Rail kit | Included |
Recorder Dimensions (H X W X D) | 17.6" x 31.9" x 3.41" (447.04 x 810.26 x 86.61mm) |
Recording Licenses (Optional. Sold Separately) |
DW-SPECTRUMLSC001 - Single DW Spectrum® IPVMS Recording License DW-SPECTRUMLSC004 - Four (4) DW Spectrum® IPVMS Recording Licenses DW-SPECTRUMLSC010 - Ten (10) DW Spectrum® IPVMS Recording Licenses DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum® IPVMS Recording Licenses DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum® IPVMS Recording Licenses DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum® IPVMS Recording Licenses DW-SPCP04LSC004 - Four (4) DW Spectrum® Analog Encoder IPVMS Licenses DW-SPIOLSC001 - Single DW Spectrum® I/O Module IPVMS License DW-SPCP16LSC016 - Sixteen (16) DW Spectrum® Analog Encoder IPVMS Licenses DW-SPVWALL1X2 - Single DW Spectrum® Video Wall IPVMS License Custom-ordered licenses are available by request. Lifetime upgrades are included with no annual renewal fees. |
Serial ports | ONVIF |
USB interface | Yes |
Warranty | 5 Year Warranty, Next business day on-site hardware service (after remote diagnosis), keep your hard drive |
Model #* | Open Drive Bays |
Available Storage, RAID5** |
Available Storage, RAID6** |
DW-BJRR2Y304T | 16TB drives, 7 open drive bays | 288TB | 272TB |
DW-BJRR2Y320T | 16TB drives, 6 open drive bays | 304TB | 288TB |
DW-BJRR2Y336T | 16TB drives, 5 open drive bays | 320TB | 304TB |
DW-BJRR2Y352T | 16TB drives, 4 open drive bays | 336TB | 320TB |
DW-BJRR2Y368T | 16TB drives, 3 open drive bays | 352TB | 336TB |
DW-BJRR2Y384T | 16TB drives, 2 open drive bays | 368TB | 352TB |
DW-BJRR2Y400T | 16TB drives, 1 open drive bay | 384TB | 368TB |
DW-BJRR2Y416T | 16TB drives, no open drive bays | 400TB | 384TB |
Part Number | Description |
DW-SPECTRUMLSC001 | Single DW Spectrum IPVMS License, No Annual Renewal, No Upgrade Required. |
DW-SPECTRUMLSC004 | Four (4) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required. |
DW-SPECTRUMLSC010 | Ten (10) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required. |
DW-SPECTRUMLSC020 | Twenty (20) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required. |
DW-SPECTRUMLSC050 | Fifty (50) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required. |
DW-SPECTRUMLSC100 | One Hundred (100) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required. |
DW-SPCP04LSC004 | Single DW Spectrum IPVMS License - allows up to 4-channel or recording when used with DW-CP04 and DW-CP16, No Annual Renewal, No Upgrade Required. |
DW-SPVWALL1X2 | Single DW Spectrum IPVMS Video Wall License - 1 Operator, 2 Monitors, No Annual Renewal, No Upgrade Required. |
Part Number | Description |
DW-BJRR32GB | 32GB Ram Upgrade for Blackjack RACK. |
DW-BJRR4NIC | Low Profile Quad Port 1GbE RJ45 for Blackjack RACK. |
DW-BJRR10GBN | Low Profile Dual Port 10Gb SFP+ NIC for Blackjack RACK. |
DW-BJRR4HSERV | Dell 4HR same day service for DW-BJRR and DW-BJRR2P servers. |
