DW-VA1G416xT

VMAX A1 G4 Universal HD over Coax 16-channel DVR
Find a Reseller Request a Demo Contact Us FAQs
Features
  • Universal HD over Coax® DVR records HD-Analog, HD-TVI and standard coax up to 4K resolution
  • Advanced H.265, H.264 Linux® embedded DVR
  • 16-channels, 480fps real-time 30fps recording
  • Up to 4K recording resolution at 112fps (7fps per channel)
  • PathFinder™ easy remote connection
  • Remote management with C3™ CMS
  • Event camera group recording
  • Complete system analysis with real-time system and network status monitoring
  • Mobile Application for iOS® and Android® devices
  • OSD and PTZ control via coax (UTC)
  • Signal hybrid detects the camera signal automatically
  • Instant channel swap, no need to disconnect or reboot the DVR
  • Snapshot Notify™: programmable interval snapshot email notifications
  • 4K (3840 x 2160) True HD, VGA and CVBS video outputs
  • Up to 32TB internal storage
  • Transfer real-time data using Real Time Streaming Protocol (RTSP)
  • HDD calculation and auto-recording configuration
    • Show More

Learn about how DW
solutions can work for you

View All Markets

PathFinder™

Easy and secure remote connection with NAT Traversal (STUN/TURN) support without opening ports.
Learn More.

Status Monitoring

A real-time graphical representation of all system connections. Receive connection alerts via email or text.

Group Recording

Designate a group of cameras to respond to an alert from one camera.

Channel Swap

Swap a camera’s channel assignment without changing the cable connections.

C3™ CMS

C3™ CMS takes video management to the next level. You are in complete command to control all your video surveillance systems in one intuitive interface. Easy-to-program alerts let you take action in real-time and manage the health of your devices.
Learn More.

Real-Time Streaming Protocol (RTSP)

RTSP provides a live video stream for live streaming applications between DW VMAX® G4 recorders and third-party software applications. RTSP streams offer a secondary backup location for recorded video and smart home integration, an alternative for ONVIF integration and a way to broadcast a stream to live streaming services, such as CCTV live monitoring in animal sanctuaries and public cameras.

Specifications

Video
Display Modes 1, 10, 16, 4, 6, 9, Sequence
Display Speed Up to 30fps per channel
Input channels 16 Channels
Local Video Output Resolution 1024x768, 1280x1024, 1280x720, 1920x1080, 2560x1440, 800x600, 3840×2160 (4K)
Local Video Outputs CVBS output, True HD, VGA
Max Supported Recording Resolution 4K (3840×2160)
Supported Signals Analog up to 960H, HD-Analog, HD-TVI
Video Compression H.264, H.265
Storage
Raw internal storage options 002TB  004TB  006TB  008TB  010TB  012TB  016TB  020TB  032TB  No Local Storage
Max HDD Bay 2 x SATA HDD
Maximum Storage 10TB (DW-VA1G41610T), 12TB (DW-VA1G41612T), 16TB (DW-VA1G41616T), 20TB (DW-VA1G41620T), 2TB (DW-VA1G4162T), 32TB (DW-VA1G41632T), 4TB (DW-VA1G4164T), 6TB (DW-VA1G4166T), 8TB (DW-VA1G4168T), No storage (DW-VA1G416)
HDD healthcheck Temperature, S.M.A.R.T. with email notifications
Performance
Alarm in/out 16 alarm outputs, 4 alarm outputs
Audio in/out 1 output, 8 inputs
Performance features Camera Color Control, Covert Channel, Digital Zoom in live and playback, Import and export settings, Real-time temp alert
Playback Functions Calendar, Event search, Smart motion search, Thumbnail search, Timeline
Playback speed x1, x16, x2, x32, x4, x64, x8, x99
Post-recording 0~5 minutes
Pre- recording 0~5 seconds
PTZ control RS485, UTC
Recording Modes Continuous, Emergency, Motion detection, Pre- and post-alarm, Quick backup, Scheduled, Sensor
Recording Resolution and Recording Rate 1280x720 (HD): 480fps, 1920x1080 (HD): 480fps, 2560x1600 (4MP): 240fps, 2560x1944 (5MP): 192fps, 3MP (1920x1536): 288fps, 4K (3840x2160): 112fps, 720x480 (SD): 480fps, 960x480 (960H): 480fps
System Operation Graphical user interface (GUI), Joystick Controller (optional), USB mouse (included)
Network
Backup Local backup via USB, Network backup via CMS
Ethernet Ports 1x 1G Ethernet (RJ45)
Firmware Upgrade CMS over network, FTP, USB
Network Remote Software C3 CMS, DW Mobile Plus, DW Site Viewer for Apple TV
Protocol DHCP, RTSP, Static fixed IP, uPNP
System recovery after power failure Auto-reboot and journaling file system
Transation verification 4K (3840x2160): 112fps
Transmission speed live 1280x720 (HD): 480fps, 1920x1080 (HD): 480fps, 2560x1600 (4MP): 240fps, 2560x1944 (5MP): 192fps, 3MP (1920x1536): 288fps, 960x480/576 (960H): 480fps
Electrical
Power Consumption 48W, 60W, A UPS is recommended
General
Accessories IR remote control (optional), Mouse
Audio codec ADPCM
Certification KCC, NDAA Compliance  RohS, TAA Compliance  UL Listed  WEEE
Form Factor Embedded
Operating Temperature and Humidity 0 ~ 80% RH, 10~90% RH, 32~113 °F (0~45 °C), 41 ~ 104 °F (5~40 °C)
Rail kit DW-G419RE (optional. Sold separately), DW-VAP19RE - 19" rackmount ears
Recorder Dimensions (H X W X D) 14.96" x 10.58" x 1.77" (380 x 268.8 x 45 mm), 15.15" x 12.4" x 1.88" (385 × 315 × 48 mm)
Serial ports RS485
USB interface Yes
Warranty 5 Year Limited Warranty

Part Numbers

Model #

Supported Cameras

Storage Size

DW-VA1G416 Up to 16 channels HD-Analog and HD-TVI and CVBS signalsNo local storage
DW-VA1G4162T Up to 16 channels HD-Analog and HD-TVI and CVBS analog signals2TB
DW-VA1G4164T
Up to 16 channels HD-Analog and HD-TVI and CVBS analog signals
4TB
DW-VA1G4166T
Up to 16 channels HD-Analog and HD-TVI and CVBS analog signals
6TB
DW-VA1G4168T
Up to 16 channels HD-Analog and HD-TVI and CVBS analog signals
8TB
DW-VA1G41610T Up to 16 channels HD-Analog and HD-TVI and CVBS analog signals
10TB
DW-VA1G41612T Up to 16 channels HD-Analog and HD-TVI and CVBS analog signals12TB
DW-VA1G41616T Up to 16 channels HD-Analog and HD-TVI and CVBS analog signals16TB
DW-VA1G41620T Up to 16 channels HD-Analog and HD-TVI and CVBS analog signals 20TB
DW-VA1G41632T Up to 16 channels HD-Analog and HD-TVI and CVBS analog signals 32TB
