Home IP Cameras DWC-MB44Wi650C5, DWC-MB44Wi650C1T

DWC-MB44Wi650C5
DWC-MB44Wi650C1T

MEGApix CaaS 4MP bullet IP camera with long range vari-focal lens and IR
Find a Reseller Request a Demo Contact Us FAQs
NDAA
Features
  • All-in-one cameras, no server required
  • 4MP 1/3” image sensor at real-time 30fps
  • 6~50mm vari-focal p-iris lens with motorized zoom and auto-focus
  • Built-in 512GB/1TB storage options for up to 60 days retained video*
  • Easily to deploy with pre-loaded DW Spectrum® IPVMS for out-of-the-box operation
  • 24/7 access to live and recorded video feed
  • Automatic installation and licensing with first power on
  • Connect up to 30 MEGApix® CaaS™ edge cameras
  • True Wide Dynamic Range (WDR)
  • Dual recording option with Blackjack® NAS appliance
  • Dual codecs (H.264, MJPEG) with simultaneous dual-stream
  • Cold start -40°F (-40°C)
  • 140’ Smart IR™ with intelligent camera sync
  • Smart DNR™ 3D digital noise reduction
  • True day/night with mechanical IR cut filter
  • Programmable privacy zones
  • Auto gain control (AGC)
    • Show More

All-in-one cameras that do not require NVR’s, DVR’s or on-premise servers

MEGApix® CaaS™ cameras act as an all-in-one solution, handling recording, notifications, management and monitoring all accessed remotely, with no need for a dedicated server or remote recorder.

Camera as a system

The CaaS™ solution supports multiple cameras in the same network, and unlimited systems all accessible and manageable via DW Spectrum® client, app and DW Cloud™.

90 days of retained video

Get access to up to 90 days of recorded data all stored locally on the camera, manageable and archived remotely.

Simple to deploy, effortless to maintain

The MEGApix® CaaS™ all-in-one cameras offer a quick and effortless path from installing the camera to watching and recording in minutes. Just install the camera, download the DW Spectrum® client software, activate the licenses and start watching.

Bandwidth conscious

Our ground-breaking architecture places video storage on the camera, not in the cloud or a remote server, placing network flow as a top priority and ensuring that critical network activities get the bandwidth they require.

Cold Start -40°F (-40°C)

The installed heater helps the camera power up in extreme cold weather conditions where temperatures may go as low as -40°F. This makes the cameras ideal for any harsh environment installation.

Specifications

Image sensor 4MP 1/3" CMOS sensor
Maximum resolution 4MP
Minimum Scene Illumination in color 0.26 lux (color), 0.0 lux (B/W)
Test Video Output Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels 2688 (H) x 1520 (V)
Stream speed
Local server recording 64GB local memory for recording, 128GB local memory for recording, 256GB local memory for recording, 512GB local memory for recording, 1TB local memory for recording
Max. number of CaaS™ cameras in the same network/system Up to 30 MEGApix® CaaS™ cameras in the same network/system
Number of DW Spectrum® CaaS™ licenses included 1 DW Spectrum® CaaS™ license included
Lens
Advanced Lens Features Motorized zoom, Auto focus, P-iris
Focal Length 6mm ~ 50mm
Horizontal Field of View (HFOV) 90° ~ 7.3°
IR Distance 140' range Smart IR™
Lens Type Vari-focal Lens
I/O
Audio compression G.711
I/O Alarm in/out 1 input, 1 output
I/O Audio in/out 1 input, 1 output, *Cameras provide a line level audio. The use of amplified microphones and speakers is recommended.
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Day and night Auto day/night, Day (color), Night (B/W)
Mirror/flip Yes
Motion Detection Yes
Operational features True D/N
Operational Notifications Email, FTP server, Alarm output activation
Privacy Zones 4 programmable privacy masks
Sharpness Yes
Shutter Mode Auto, Manual, Slow Shutter, Anti-Flicker
Shutter Speed 1/15 ~ 1/32000
Slow Shutter Speed Off, x5, x7.5, x10
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Network
Bitrate Control Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth)
IP IPv4
LAN 802.3 compliance 10/100 LAN
Network resolution H.264: 1440p, 2.1MP/1080p, 720p, VGA, D1, CIF, MJPEG: 1280x720, 800x600, VGA, 768x432, D1, CIF
Network Web Viewer Windows® OS, Mac® OS, Linux® OS, Internet Explorer® browser, Google Chrome® browser, Mozilla Firefox® browser, Safari® browser
Protocol DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Security HTTPS (TLS), IP filtering, 802.1x, Digest authemtication (ID/PW)
Stream Speed Up to 30fps at all resolutions
Video Bitrate 100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type H.264, MJPEG
Video Management Software DW Spectrum® IPVMS
Environmental
Compliance NDAA Compliance, UL Listing  CE, FCC  RoHS, ONVIF
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -40°F ~ 122°F (-40°C ~ 50°C)
Mechanical
Camera Dimensions (H X W X D) 4.66" x 3.58" (118.6 x 91 mm), 4.92" x 2.9" (125 x 74.3 mm), 9.73” x 3.8” (247.2 x 96.7mm), *Dimensions based on the position of the sun shield cover
Camera Weight 1.98 lbs (0.9kg)
Housing Bullet
IP rating Weather Resistant (IP66)
Materials Aluminum die-casting
Electrical
Power Consumption DC12V: max 11.0W, 916.6mA, PoE: max 12.9W
Power Requirements PoE, IEEE 802.3af Class 3, (Adapter not included), 12V DC
General
Warranty 5 Year Warranty

Part Numbers

Model #

Storage size
DWC-MB44Wi650C5
512GB
DWC-MB44Wi650C1T 1TB

Accessories

DWC-BLJUNC
Junction box for bullet cameras
Learn more
DWC-PMB-BU
Pole mount bracket for bullet cameras
Learn more
