DWC-PVF5Di1TW
DWC-PPVF5Di1TW

MEGApix 5MP fisheye IP camera with fisheye lens and IR
Features
  • 5MP sensor at real-time 30fps
  • Star-Light Plus™ color in near-total darkness technology
  • Intelligent Video Analytics (IVA) with extended features (IVA+)
  • Seamless integration and control of IVA rules with DW Spectrum® IPVMS
  • Reduce false alarms
  • Increase your recording storage with logic rules and smart recording
  • 1.5mm fisheye lens with 360° hemispheric view
  • Support 360° hemispheric fisheye view and 360°, 180° and 90° panoramic view
  • Edge-to-edge image clarity with no pixel loss
  • Simultaneous streaming and multiple codec options for smart bandwidth management
  • 360° 80' Smart IR™ with intelligent camera sync for clear B/W images with no need for external light
  • Smart DNR™ 3D digital noise reduction reduces noise and ghosting for motion in low-light environments.
  • Two-way audio for direct communication between the monitoring station and the camera's location
  • Local SD card slot for local recording in case of network loss
  • Web server built-in for easy camera management from any browser
  • PoE and DC12V for single cable simplified installation
  • NDAA compliant for federal and government projects
  • Show More

Complete situational awareness with a single camera

Fisheye cameras can cover complete room monitoring with situational awareness and a 360 hemispheric image that can be dewarped with minimal loss of pixels. The result is a more efficient way to monitor indoor spaces with one solution replacing multiple cameras.

360° hemispheric and panoramic fisheye views at real-time 30fps

360° fisheye view IP cameras MEGApix® Pano™ 360° view fisheye cameras with IR monitor an entire room with a single camera, providing the ultimate ROI.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

Megapixel resolution

DW’s technology delivers crystal clear images in any resolution. Higher-resolution offers forensic details with zooming into the camera’s field of view.

IVA Analytics

MEGApix IVA cameras include a base package of Intelligent Video Analytics detection capabilities already activated on the camera and ready for deployment.

Learn More.

IVA+ Analytics

The MEGApix IVA+ package offers advanced rules to the IVA Video Content Analysis detection capabilities.

Learn More.

Specifications

Active Pixels 2592 (H) x 1944 (V)
Image sensor 6.4MP 1/1.8" CMOS sensor
Maximum resolution 5MP
Minimum Scene Illumination in color 0.0 lux (B/W), 0.039 lux (color)
Total Pixels 4000 (H) x 3000 (V)
Lens
Focal Length 1.55mm
Horizontal Field of View (HFOV) 185°
IR Distance 80' range Smart IR™
Lens Type Fixed Lens
Vertical Field of View (VFOV) 185°
I/O
Audio compression G.711
I/O Alarm in/out 1 input, 1 output
I/O Audio in/out 1 input (1.0Vms, 3K ohm)
Intelligent Video Analytics
IVA license Intrusion, line crossing, counting line, loitering, enter, exit, tamper
IVA+ license Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Backlight compensation (BLC) Yes
Day and night Auto day/night, Day (color), Night (B/W)
De-fog Yes
Memory slot Micro SD/SDHC/SDXC class 10 card (card not included), Up to 1TB micro SD / FAT32
Mirror/flip Yes
Motion Detection Yes
Operational Notifications Alarm output activation, Email, FTP server, SD card recording
Privacy Zones 16 programmable privacy masks
Shutter Mode Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed 1/15 ~ 1/32000
Slow Shutter Speed Off, x10, x2, x3, x5, x6, x7.5
White Balance Yes
Network
Bitrate Control Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
IP IPv4
LAN RJ45 (10/100Base-T)
Network resolution H.264: 2592x1944, 2048x1536, 1600x1200, 1280x1024, 800x600, 480x360, 320x240, H.265: 2592x1944, 2048x1536, 1600x1200, 1280x1024, 800x600, 480x360, 320x240, MJPEG: 1280x1024, 800x600, 480x360, 320x240
Network Web Viewer Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol Bonjour, DDNS, DHCP, DNS, Genetec Protocol, HTTP, HTTPs, IGMP, NTP, RTP, RTP (UDP/TCP), RTSP, SNMP, SNMPv1/v2/v3 (MIB-2), TCP, Telnet, UPnP, Zeroconf (AutoIP)
Security 802.1x, HTTPS (TLS), MAC filtering, Multi-user authority
Stream Speed Up to 30fps at all resolutions
Streaming Capability Dual-stream at different rates and resolutions
Video Bitrate 100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type H.264, H.265, MJPEG
Video Management Software DW Spectrum® IPVMS, ExacqVision Technologies, Milestone Systems
Environmental
Compliance CE  FCC  NDAA Compliance  ONVIF  UL Listing
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Optional. Sold separately
Mechanical
Camera Dimensions (H X W X D) 4.92" x 1.88” (125 x 48 mm)
Camera Weight 1.10 lbs (0.5kg)
Housing Fisheye
Housing Color White
IK rating IK09 Rated
IP rating Weather Resistant (IP66)
Materials Aluminum die-casting
Electrical
American wire gauge (AWG) Cable type #18
Power Consumption DC12V: max 7.5W, 625mA, PoE: max 8.7W
Power Requirements Adapter not included, PoE
General
Warranty 5 Year Warranty

Part Numbers

Part Number Description
DWC-PVF5Di1TW preloaded with IVA.
DWC-PPVF5Di1TW preloaded with IVA+.

Accessories

DWC-VFCMW
Ceiling mount bracket for selected vandal dome and turret cameras - White
Learn more
DWC-GPLT-W
Converter plate for electronic gang box - white
Learn more
DWC-V1CNMW
Corner and pole mount bracket - White
Learn more
DWC-VFHMW
Hanging mount for selected vandal dome and fisheye cameras for custom built arm mount - white
Learn more
DWC-VFJUNCW
Junction box for selected vandal dome and turret cameras - White
Learn more
DWC-WMJUNCW
Junction box for wall mounts and dual-sensor IP cameras - white
Learn more
DWC-PMB-WLW
Pole mount bracket - white
Learn more
DWC-VFWMW
Wall mount bracket for selected vandal dome and turret cameras - White
Learn more
